Dell Latitude E5470 E5570 Precision 3510 4 Cell 62Wh Battery Type 6MT4T HK6DV

Dell Latitude E5470 E5570 and Precision 3510 Primary Battery

Condition: New Dell Stock
Brand New 6MT4T battery for Dell Latitude, E5470, E5570 7.6V 62Whr 4C Lithium-Ion 7V69Y TXF9M 79VRK HK6DV. Free next-day delivery and same-day shipping on orders placed before 4 pm.

Type Number: 6MT4T
Part Numbers: K3JK9, 7V69Y
4-Cell Primary Battery
7.6v - 62Wh Capacity

Laptops this battery fits:

Dell Latitude E5470 Battery

Dell Latitude E5570 Battery

Dell Precision 3510 Battery


Please Note: Some models require a cable that goes from the battery to the motherboard. Please keep the cable from the old battery.

Supplied with 12 months warranty. If you have any questions, please call us on 01243 866053

How to install the battery

PLEASE NOTE: We are not liable for any hardware damages or injury caused during the installation. We also recommend using anti-static equipment to prevent hardware damage.

Removing the old battery

1. Power off the laptop.

2. Turn over the laptop and unscrew the base plate cover.

3. Remove the base plate from the laptop (Use a prying tool to help unclip in necessary)

4. Identify the battery connector and unplug the battery. (Slide the battery connecter away from the motherboard connector)

5. Unscrew the battery and remove the battery from the laptop.

Installing the New Battery

1. Align the new battery into position (Do not plug the battery in yet)

2. Install the battery screws

3. Plug the battery cable into the motherboard

4. Replace the base plate by applying light pressure to ensure it's seated correctly.

5. Install the base plate screws

6. Plug the power adapter into the laptop and switch on the laptop.
